| Parameter |
Specification |
| Mounting Type |
Floor mounted |
| Number of Grinding Bowls |
1 (Working) |
| Bowl Capacity |
Minimum 450 ml per bowl |
| Maximum Feed Size |
Up to 6 mm |
| Discharge Size |
≤ 75 microns |
| Feed Material Type |
Medium to high hardness & brittle materials |
| Material Examples |
Bauxite, Concrete, Ores, Ferro Alloys, Quartz, Glass, Granite,
Cement Clinker, Slag, Coal, Coke, Corundum, Tungsten
|
| Material Hardness Range |
3 – 8 Mohs Scale |
| Grinding Liner Material |
Hardened Steel |
| Grinding Elements |
1 Bowl + 1 Ring + 1 Disc/Hammer per set |
| Contamination Control |
Non-reactive, contamination-free grinding environment |
| Noise Level |
Below 76 dB (with soundproof enclosure) |
| Cleaning System |
Cleaning kit and accessories provided |
| Timer |
Inbuilt programmable timer |
| Motor Power |
Minimum 2 HP (1.5 kW) |
| Power Supply |
415V AC, 3 Phase (±15%) OR 230V AC, Single Phase (±15%), 50/60 Hz |
| Accessories |
Complete operational set included in supply |
