Specifications
| Leeb probe types | D, DC, D/C, D+15, E, G |
| Measurement range |
Vickers HV: 240~940, Rockwell HRC: 20~70,
Brinell HB: 90~650 Tensile strength, MPa 370~1740 Measurement ranges can be expanded by the user (for example: 1~2000HV) |
| Measurement accuracy | ±15HV, ±2HRC, ±10HB, ±4HLD |
| Scales | Leeb probe; HRC, HRB, HB, HV, HS, HRA, MPa, HD |
| Materials |
Leeb probe – pre-calibrated for steel, alloy steel,
stainless steel, cast iron Additional custom scales and materials for calibration |
| Measuring direction | Any direction 360° |
| Data storage |
Device – 4GB SD card (~13000 measurements) A5 Lab App – limited only by the memory of the Android gadgets Cloud storage – limited only by the memory of the Cloud storage |
| Data transfer |
Wireless connection with Android smartphones, tablets, etc. –
ASI Lab App PC – Web interface – ASI.INFO |
| Languages | English |
| Power supply / Charging | 3 pcs AA batteries / 5V USB |
| Batteries life | 10 h |
| Operating environment | Temperature: -20°C ~ 50°C, Humidity: <95% R.H. at 35°C |
|
Dimensions and weight of electronic unit (with batteries) |
160×75×30 mm / 0.3 kg |
