| Specification |
| Model |
ASI-eMP-2D |
| Mold diameter |
Select two from Ø25/30/45mm (50mm customized). Two independent positions controlled by two touch screens. Special high hardness mold cylinder design, never scratched. |
| System pressure |
0-10MPa |
| Heater power |
Ø25/30mm: 1.5KW; Ø45mm: 1.8KW. Special fast heating design — heating rod instead of heating coil, more efficient heat transfer and longer service life. |
| Mosaic temperature range |
35-300°C adjustable |
| Mosaic time |
5-6 minutes to prepare a sample |
| Pressure Loading |
Automatic loading pressure (hydraulic system) |
| Cooling |
Water cooling (Chiller optional) |
| Mounting program |
Can edit and save 10 mounting programs |
| Operation and display mode |
8-inch touch screen (2 units) |
| Working mode |
Automatic |
| Power supply |
AC220V 50Hz |
| Dimension & weight |
650×700×500mm; 100kg |
| Packing size & G.W. |
835×715×560mm; 115kg |
