Flow Table - ASI-521

It is used for determining the flow of cement concrete.

Specifications: Same as above but electrically operated, to raise and drop the table top, approx. 15 times in 15 seconds. Suitablefor operation on 230 Volts, 50 cycles, A.C. supply. Specifications: Consists of a steel table top 76.2cm (30 inch. Dia.), finely machined. The integral cast ribs are designed for supportand strength. The stand is fabricated out of cast iron and is of study construction. Hole for mounting in foundations are drilled in thebase plate. The ground and hardened steel cam is designed to lift and drop the table by 12.5mm. The hand wheel makes it simple tooperate the table. Supplied with one conical mould with handles. 12cm. height having 17cm. top inernal diameter and 25cm. I.D. at the base complete with a tamping rod 16mm. dia x 600mm long one end rounded.
