| Max Load (kgf) |
3000 |
| Load range (kgf) |
IN STAGE OF 250KGF |
| Initial Load range (kgf) |
250 |
| Max. test height (mm) |
410 |
| Depth of throat (mm) |
200 |
| Size of base (mm) |
670 X 370 |
| Machine height (mm) |
1127MM |
| Nett. Weight (Approx.) kg. |
450KG |
| Test Performed |
Brinell |
| Testing Table 200 mm Ø |
1 Pc |
| Testing Table 200 mm Ø with ‘V’ grove for round jobs 10 to 80 mm dis |
1 Pc |
| Ball holder 5 mm |
1 Pc |
| Ball holder 10 mm |
1 Pc |
| Test Block HB-5/750 |
1 Pc |
| Test Block HB-10/3000 |
1 Pc |
| Brinell Microscope |
1 Pc |
| Allen Spanner |
1 Pc |
| Telescopic cover for elevating screw protection |
1 Pc |
| Instruction Manual |
1 Pc |
