Brinell Hardness Tester Fully Automatic - AMT-3000PC

Features:

Automatic testing process, just press one key—machine will automatically focus, load, measure, and display the test result.
The test force value ranges from 162.5kgf; 16 kinds of Brinell scales, which can be customized by users.
The Z-axis rises and falls automatically. After placing the sample, it rises automatically and begins to make an indentation.
Closed-loop control with high precision load cell design; automatic loading, dwell, unloading, and indentation measurement. No need for weights or debugging—easy installation and maintenance.
Automatic turret—indenter and measurement positions switch automatically.
On-screen calibration using standard hardness block is easy and efficient.
Large test space—maximum sample height: 305mm; throat depth: 195mm. Suitable for large samples.
Digital eyepiece with encoder simplifies the measurement process.
Hardness conversion function—can convert directly to Rockwell, Vickers, Knoop, etc. based on needs.
Optional camera and software system for automatic hardness measurement and custom report generation.

Brinell Hardness Tester Specs

Technical Specifications:
Model	AMT-300PC
Turret	Automatic
Z Axis	Automatic, moves up/down
Brinell Scale	HBW1/2.5, HBW2.5/6.25, HBW2.5/15.625, HBW2.5/31.25, HBW2.5/62.5, HBW5/25, HBW5/62.5, HBW5/125, HBW5/250, HBW5/500, HBW10/100, HBW10/125, HBW10/250, HBW10/500, HBW10/1000, HBW10/1500, HBW10/3000
Conversion Scale	HRA, HRB, HRC, HRD, HRF, HRB, HRN, HRE, HK, HV, etc.
Test Load (Kgf)	1.25, 2.5, 3.125, 4.9, 6.25, 7.8125, 9.8, 12.5, 15.625, 24.5, 25, 31.25, 49, 62.5, 78.125, 98, 125, 245.2, 250, 306.5, 490, 612.9, 735.5, 980.7, 1226, 1471, 1839, 2452.7, 2942, 3060
Devices	20X electronic eyepiece
Objective Lens	5X, 10X (Total magnification: 50X, 100X)
Min Measuring Unit	0.1HBW
Hardness Range	8-650HBW
Data Output	Built-in Printer
Operation	Automatic: press one key the work table will automatically rise up, perform auto loading - dwell - unloading, auto measure indentation & get Brinell hardness value. Works with software & camera for auto measure.
Standard	ASTM E10-2024, ISO 6506, ISO 6508, GB/T231.2
Max Sample Height	305mm
Depth	305mm (distance to machine wall)
Machine Size	680×250×680 mm
Weight	110kg
Power Supply	AC220V, 50–60Hz

Item	Quantity	Item	Quantity
Standard Accessories:
Measuring microscope 20X	1	AMT soft cover	1
Accessories box	1	V-type working table	1
Calibration block	1	Medium working table	1
Standard hardness block	2	Large working table	1
Software & USB driver	1	Camera / eyepiece (20X + encoder)	1
