| Model |
ASI-eMP-1E |
| Mold diameter |
Ø25mm, Ø30mm, Ø40mm, Ø50mm |
| Mold cavity height |
135mm, effective height 80mm, Support double spacer (2 samples) |
| Mounting programming |
Programmable database, can store 10 groups of Mounting programs |
| Pressure setting range |
0–10MPa adjustable |
| Heater power |
1.5KW, total system 1.8KW |
| Mounting temperature range |
35–200°C adjustable |
| Pressure holding time range |
1–99min |
| Pressure Loading |
Automatic loading pressure (by hydraulic system) |
| Automatic cooling down time |
0–60min |
| Cooling |
Water cooling (Chiller as optional purchase) |
| Mounting program |
Can save 10 groups mounting programs |
| Operation and display mode |
8 inch touch screen |
| Power supply |
AC220V 50HZ |
| Dimension & N/W |
625×583×565mm; 83kg |
| Packing size & G/W |
915×710×797mm, 104kg |
