| Technical Specifications: | |
|---|---|
|
Size : 24 × 24 × 24 ASTM B117: Methods of Testing Corrosion Resistance of Electroplated and Anodized Aluminum Coatings MS Powder Coatings by Neutral Salt Spray Test |
|
| 1. Temp. range | 35°C±1°C / 50°C ±1°C |
| 2. Temp. uniformity | ±2°C |
| 3. Temperature fluctuation | ±0.5°C |
| 4. Temperature sensor | PT 100 |
| 5. Humidity range | 95% |
| 6. - | Humidity indicator |
| 7. Controller type | 01 No. PID temperature controllers for chamber and pressure vessel |
| 8. Timer | Digital timer 9999 hours |
| 9. Canopy | Made of PP Manual lifting |
| 10. Chamber construction | PVC (10 mm) reinforced hard plastic sheet for complete corrosion proof construction |
| 11. Salt fog | Fallout rate 1 ~ 2ml per 2 per hour |
| 12. Spray mode | Continuous or intermittent spray |
| 13. - | Compressed Air pressure 1.00 ±0.01kgf/cm² |
| 14. - | Glass nozzle |
