| Standard Accessories - Model: AMT-5D | |
|---|---|
| Testing Table 50mmØ | 1 Pc |
| Testing Table 40mmØ | 1 Pc |
| With 'V' groove for Round jobs 6 to 45 mm Ø | 1 Pc |
| Diamond Indenter 120° | 1 Pc |
| Steel Ball Indenter 1/16” | 1 Pc |
| Test Block Rockwell 'C' | 1 Pc |
| Test Block Rockwell 'B' | 1 Pc |
| Test Block Rockwell Superficial 'N' | NIL |
| Alien Spanners | 2 Pc |
| Clamping device | 1 Pc |
| Dash pot oil | 1 bottle |
| Instruction Manual | 1 book |
| Brinell Microscope | 1 Pc |
| Steel Ball Indenter 2.5mm | 1 Pc |
| Steel Ball Indenter 5mm | 1 Pc |
| Test Block HB-2.5/187.5 | 1 Pc |
| Technical Specification - Model: AMT-5D | |
|---|---|
| Max load (kgf) | 250 |
| Load range (kgf) | 60, 100, 150, 187.5, 250 |
| Initial Load range (kgf) | 10 |
| Max. test height (mm) | 290 |
| Depth of throat (mm) | 148 |
| Size of base (mm) | 210 x 510 |
| Machine height (mm) | 845 |
| Nett. Weight (Approx.) KG. | 137 |
| Test Performed | Rockwell & Brinell |
