| Standard Features | |
|---|---|
| X-Y Bed Size | 150mm × 150mm |
| Travel X-Y movement (Standard) | 25mm × 25mm |
| Micrometers (50mm Dia) | 25mm (L.C 0.01 mm) |
| Angular Measurement | Manual, 360° graduated ring with vernier |
| Maximum size of object view | 18mm (dia) |
| Max Working Distance | 30 mm Approx |
| Standard Magnifications | 10x, 20x, 50x & 100x |
| Standard Accessories | Dust Cover, Electric Fuse, Instruction Manual |
| Optional Accessories (at extra cost) | Magnification 40x or 80x, Digital Micrometers, Halogen Bulb |
