| Specification |
| Control mode | A8 Embedded platform |
| Data storage | ≥4GB |
| Operation mode | Key + touch screen |
| Sentinel magnify(time) | 1,2,5,10,20,50,100 adjustable |
| A/D resolution(bit) | True 24 bits A/D |
| Sampling time intervals(μS) | 1~64000 adjustable |
| Max length of sampling | 4096 |
| Trigger | Signal trigger |
| Noise voltage of the system(mV) | ≤1 |
| Dynamic range(dB) | ≥184 |
| Amplifier frequency range(Hz) | 10~10K |
| Time value error | 4096 |
| Time resolving power(us) | ≤10% |
| Gain error(dB) | ≤1% |
| Work time(h) | >8 |
| Number of channels | 2 |
| Interference between the channels | ≤1% |
| Transducer/probe sensitivity (Acceleration mode) (mv/g) | ≥100 |
| Frequency range of Probe (Acceleration probe) (Hz) | 0.5~9000 |
| Port | Double USB |
| Wi-fi | Yes |
| Power |
Internal: Built-in battery |
| External: 220VAC/DC |
| Operational environment |
Temperature (℃): -10~+50 |
| Humidity (RH): <90% |
