Technical Specifications
| Parameter | Specification |
|---|---|
| Chamber Type | Enclosed cabinet with transparent viewing window |
| Chamber Inner Dimensions |
Width: 120–125 cm Height: 125–130 cm Depth: 60–35 cm |
| Power Supply | 220–240 V, 50 Hz |
| Gas Pressure Gauge | 0–30 psi with regulator |
| Methane Gas Flow Meter | 0–150 ml/min (Accuracy: 1 ml/min) |
| Digital Timer | 0–999 sec (Accuracy: 0.5 sec) |
| Burner Inclination | 0°, 20°, 45° adjustable |
| Control System | Touchscreen, Microprocessor-based |
| Exhaust System | Integrated exhaust blower |
| Temperature Monitoring | Flame temperature sensor with digital display |
