| Features |
| 1 | The apparatus can automatically measure and control all experimental processes using a single-chip microcomputer and a 10-inch touchscreen LCD, showing temperature, volume, and related curves. |
| 2 | Accept the cylinder bath temperature via automatic control. |
| 3 | The apparatus adopts a quartz base plate. |
| 4 | Automatic nitrogen fire extinguishing is supported. |
| 5 | Tracks the liquid level automatically and controls flow velocity. |
| Technical Parameters |
| 1 | Rated voltage: AC220V±10% 50Hz or 110V±10% 60Hz |
| 2 | Power: 1200W |
| 3 | Temperature range: Environment temperature to 400°C |
| 4 | Temperature control precision: ±0.1°C |
| 5 | Temperature sensor: RTD Pt100 |
| 6 | Start heating to initial distillation point time: 5~15 min |
| 7 | Distillation rate: 4~5 ml/min |
| 8 | Residues in flask (5 ml): Less than 5 min |
| 9 | Initial distillation point temperature detection: Optical fiber sensors |
| 10 | Recycling volume measurement range: 0~100 ml |
| 11 | Recycling volume measurement precision: ±0.1 ml |
| 12 | Ambient requirements: Temperature 10°C~40°C; Humidity ≤85% |
| Package Information |
| 1 | Dimension: 710×610×820 mm |
| 2 | Volume: 0.36 m³ |
| 3 | Weight: 94 kg |
