ASI-MoPao2 (Single disk) - Technical Parameters
| Specification | ASI-MoPao2 (Single disk) |
|---|---|
| Voltage | Single-phase AC220V 50Hz |
| Input power | 1.1KW |
| Wheel diameter | φ250mm (Standard), Optional φ203mm, φ300mm |
| Wheel speed |
50 ~ 600 r/min (Stepless speed) 150 r/min, 300 r/min (Constant speed) |
| Wheel direction | Adjustable clockwise or counterclockwise |
| Power head speed | 50 ~ 150 r/min (Stepless speed) |
| Single point loading | 5 ~ 60N |
| Number of samples | 4 pcs (Standard) |
| Sample size | φ30mm (Standard), Optional φ22mm, φ25mm, φ30mm, φ40mm, φ45mm, φ50mm |
| Sample preparation time | 0 ~ 995s (S) |
| Compressed air pressure | 0.6 ~ 0.9MPa |
| Dimensions | 594 × 795 × 687mm |
| Net weight | 98Kg |
| Gross weight | 125Kg |
